MS8212 Mastech in Pakistan

Description:

This meter is a portable professional measuring instrument with

handsome LCD easilyreading. Single operation of a transform switch

makes measurement convenient. Overload protection and low battery

indication are provided, this meter is ideal for usein the fields,

workshop, school, hobby and home applications

Accuracy is specified for a period of year after calibration and at 18℃ to 28℃

(64℉ to 82℉) with relative humidity to 75%.

• Environment conditions: 600V CAT III
• Pollution degree: 2
• Altitude < 2000m
• Operating temperature: 0℃ to 40℃(32℉ to 122℉) (<80%RH,<10℃ non-condensing)
• Storage temperature: -10℃ to 50℃ (10℉ to 122℉) (<70%RH,battery removed)
• Max. Voltage Between Terminals And Earth Ground: 600V DC or AC
• Auto range and manual range.
• Display: 20 mm LCD
• Max. Show Value: 1999 (3 1/2)
• Polarity indication: ” – ” indicates negative polarity.
• Over range indication: Display “OL”
• Sampling time approx. 0.4 second
• Unit showing: Showing of function and electrical capacity.
• Low battery indication: displayed
• Fuse protection: FF400mA H 600V
• Automatic power off time: 15 min.
• Power supply: 1.5Vx2 AAA Batteries
• Dimension (LxWxH): 222x43x29mm
• Weight: approx. 129g (including battery)

Features:

• Pen-Type Design and Autoranging
• Built-In Non-Contact Voltage Detector
• Test AC/DC Voltage and Current, Resistance
• Retractable Tip Design
• Diode Check and Continuity Test
• Data Hold and MAX Hold
