WED 9618 Digital Ultrasound Portable Machine
₨ 320,000
Add to wishlist
Description
Product Description
Full Digital Ultrasonic Diagnostic System (WED-9618)
Portable ultrasound Wed-9618 is the best choice of Welld. It is a cost-effective solution in any specialty, is distinguished by its Full digital technology Beamforming which provides bright and clear image quality. Interchangeable probes offer a wide range of applications.
WED-9618 Ultrasound Diagnostic Apparatus For clinical ultrasonography of abdomen, obstetrics, gynecology, organelle, small organ, superficial organs, urology, cavity, cardiology and cardiovascular.
Features
WED-9618 adopts multiple technologies such as micro-computer control and digital scan converter (DSC), digital beam-forming (DBF), real time dynamic aperture (RDA), real time dynamic receiving apodization(DRA), real time Dynamic receiving focusing (DRF), Digital frequency Scan (DFS) which can display a high quality, stable and high resolution image. The external Video printer and external monitor display can be realized with the PAL-D Video output port.
All the ultrasound images can download to PC with high speed USB 2.0 port. Various image processing software packages are available.
Unit Parameters
Function |
Detail |
| Scanning Model | Electronic Linear Array, electronic convex array |
| Cine-loop | ≥400 frames |
| Image Storage | ≥32 frames |
| Display Depth | ≥250mm |
| Scanning Angle | Visible and adjustable |
| Display Mode | B、B+B、B+M、B+M/M、M、4B |
| Operation Interface | Chinese/English switchable |
| TGC Adjustment | Near Field, Far Field, Total Gain Independent Adjustment |
| Focus Control | Focus Number, Focus Distance, Focus Position Adjustment |
| Image Processing | Image Black/White, Gamma Correction, Edge Enhancement and Histogram |
| Real-time Depth | 16 levels are adjustable |
| Zoom | ≥2 times |
Accessories:
Convex Probe
Battery ( Backup time 2-3hrs)
Power Cable
