SCI340-4 Digital Hotplate in Pakistan

Independent heating and stirring control
LCD displays show set temperatures & speeds and real-time temperatures & speeds
PID controller ensures a precise and accurate heating process
Max. temperature up to 340℃
Brushless DC motor for powerful speed control and maintenance free
External PT1000 temperature sensor, sensor stand and accessories sold separately
Overheating protection temperature at 420℃
Stainless steel work plate with ceramic coating provides good chemical-resistance
A wide variety of accessories are available
2-year warranty
-Stirrer 4-Channel, Ceramic Plates, 340ºC / 1500rpm Max.

Work plate dimension	Ø135mm (5 inch)
Plate material	Stainless steel with ceramic coating
Motor type	Brushless DC motor
Stirring positions	4
Max. stirring quantity of single position (H₂O)	10L
Max. magnetic bar	40mm
Speed range	200-1500rpm
Speed display	LCD
Temperature display	LCD
Control accuracy of sensor	±20rpm
Temperature range	25-340°C
Over temperature protection	420°C
Temperature display accuracy	±0.1°C
External temp. sensor PT1000 Accuracy	PT1000( accuracy ± 0.2°C)
IP Protection class	IP21
Motor rating input	1.8Wx4
Power	515Wx4
Heating Power	500Wx4
Voltage	100-120V,60Hz; 200-240V,50 Hz
Dimensions[WxDxH]	698x270x128mm
Weight	9.5kg
Permissible ambient temperature	5-40°C
Permissible relative humidity	80%RH
